Description
Following a legacy of successful deployments, the next generation Granit XP scanners expand capabilities and redefine ultra-rugged scanning. Granit XP is engineered to keep on working after the impact of drops from loading docks, fork trucks, and picking trucks.
Bad labels commonly occur in the warehouse/DC and industrial space due to low quality printing or damage during handling. Granit XP, built on Honeywell’s next-generation imaging platform, ensures that otherwise challenging labels do not create a bottleneck in your process.
- Ultra-rugged
- Premium scanning performance
- Intuitive user feedback
- Ultra-rugged
Granit XP is designed to thrive in your challenging operating conditions. - Premium scanning performance
Granit provides extreme performance scanning, even on damaged and low-quality barcodes. High-quality barcodes scan and transmit faster than ever. - Intuitive user feedback
Bright aimers, configurable beeper, good read indicators, and Bluetooth and battery status indicators ensure users have all the information they need.
Main Specifications
Product Description | Honeywell Granit XP 1990iSR – USB Kit – barcode scanner |
Type | Barcode scanner – handheld – USB – decoded |
Minimum Bar Width | 3 mil |
Scan Element Type | 2D imager |
Sensor Resolution | 1280 x 800 |
Connectivity Technology | Wired |
Dimensions (WxDxH) | 7.6 cm x 19.2 cm x 10 cm |
Weight | 320 g |
Extended Specifications
General
Type | Barcode scanner – handheld |
|---|
Barcode
Interface Type | USB |
|---|
Minimum Bar Width | 3 mil |
|---|
Scan Element Type | 2D imager |
|---|
Sensor Resolution | 1280 x 800 |
|---|
Max Working Distance | 8.37 cm |
|---|
Skew (Degrees) | 65 |
|---|
Pitch (Degrees) | 45 |
|---|
Print Contrast Signal (PCS) | 20% |
|---|
Decode Capability | Code 39, UPC, PDF417, QR code, Data Matrix |
|---|
TTL Decoding | Decoded |
|---|
Connectivity Technology | Wired |
|---|
OK Notification | Vibration, beeper, LED indicator |
|---|
Features | 20 kV ESD protection (air discharge), 8 kV ESD protection (contact discharge), rugged |
|---|
Expansion / Connectivity
Miscellaneous
Cables Included | 1 x USB cable – external – 3 m |
|---|
Compliant Standards | IP67, IP65, MIL-STD 810G |
|---|
Power
Power Device | Barcode scanner charging stand |
|---|
Power Consumption Operational | 2.35 watt |
|---|
Electric Current Required | 100 mA (standby), 470 mA (operating) |
|---|
Dimensions & Weight
Width | 7.6 cm |
|---|
Depth | 19.2 cm |
|---|
Height | 10 cm |
|---|
Weight | 320 g |
|---|
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|
Max Operating Temperature | 50 °C |
|---|
Humidity Range Operating | 0 – 95% (non-condensing) |
|---|
Drop Specification | 3 m |
|---|
