Description
The Epson SureColor series is a versatile and compact range of printers. They are designed for users who need to produce large-format color and black-and-white images, economically and at high speed. They are compatible with a wide range of media from basic bond paper, to photographic media.
- High convenience
- Superior productivity
- Compact design
- Easy integration
- High convenience
Large touchscreen panel with easy-to-use interface, top loaded ink and media, spindle roll loading, integrated auto sheet feeder, auto sheet/roll switching, single page prints are held by the printer for easy removal while the floor standing model ships with a basket. - Easy integration
Compact design, high-speed Gigabit Ethernet, and convenient Wi-Fi.
Main Specifications
Product Description | Epson SureColor T3160 – large-format printer – colour – ink-jet |
Printer Type | 24" large-format printer – ink-jet – colour |
Weight | 27 kg |
Inkjet Technology | Epson PrecisionCore |
Ink Palette Supported (Colours) | 4-ink – cyan, magenta, yellow, black |
Max Media Size | Roll (61 cm) |
Max Media Size (Custom) | 610 mm |
Max Resolution (B&W) | 2400 x 1200 dpi |
Max Resolution (Colour) | 2400 x 1200 dpi |
Max Resolution Class (B&W) | 2400 x 1200 dpi |
Max Resolution Class (Colour) | 2400 x 1200 dpi |
Cutter | Yes |
Interface | Gigabit LAN, Wi-Fi(n), USB 3.0 |
AirPrint Enabled | Yes |
Preview Screen Size | 4.3" |
RAM Installed (Max) | 1 GB |
Language Simulation | HP RTL, HP GL/2, EPSON ESC/P Raster |
Media Type | Plain paper |
Networking | Print server |
System Requirements | Microsoft Windows XP, Microsoft Windows Vista, Microsoft Windows 7 (32/64 bits), Apple MacOS X 10.8.x, Windows 8.1 (32/64 bits), Apple MacOS X 10.9.x, Apple MacOS X 10.10.x, Windows 10 (32/64 bits), Apple MacOS X 10.11.x, Apple macOS 10.12.x, Apple macOS 10.13.x |
Dimensions (WxDxH) | 97 cm x 50.5 cm x 23 cm |
Documents
Extended Specifications
General
Printer Type | 24" large-format printer – ink-jet – colour |
|---|
Printer
Inkjet Technology | Epson PrecisionCore |
|---|
Ink Palette Supported (Colours) | 4-ink – cyan, magenta, yellow, black |
|---|
Nozzle Configuration | 800 nozzles (black), 3 x 800 nozzles (cyan, magenta, yellow) |
|---|
Minimum Ink Droplet Size | 4 pl |
|---|
Ink Cartridge Configuration | 4 individual ink tanks |
|---|
Ink Type | Epson UltraChrome XD2 Ink |
|---|
Built-in Devices | Touch screen |
|---|
Preview Screen Size | 4.3" |
|---|
Connectivity Technology | Wireless |
|---|
Interface | Gigabit LAN, Wi-Fi(n), USB 3.0 |
|---|
AirPrint Enabled | Yes |
|---|
Max Resolution (B&W) | 2400 x 1200 dpi |
|---|
Max Resolution (Colour) | 2400 x 1200 dpi |
|---|
Max Resolution Class (B&W) | 2400 x 1200 dpi |
|---|
Max Resolution Class (Colour) | 2400 x 1200 dpi |
|---|
First Print Out Time B/W | 34 sec |
|---|
First Print Out Time Colour | 34 sec |
|---|
Language Simulation | HP RTL, HP GL/2, EPSON ESC/P Raster |
|---|
Auto Cutter | Yes |
|---|
RAM
Media Handling
Media Type | Plain paper |
|---|
Max Media Size | Roll (61 cm) |
|---|
Max Media Size (Custom) | 610 mm |
|---|
Media Sizes | A4 (210 x 297 mm), A3 (297 x 420 mm), A1 (594 x 841 mm), Roll A1 (61.0 cm), Roll (32.9 cm) |
|---|
Media Thickness Range | 0.05 mm – 0.21 mm |
|---|
Media Feeders | 1 x manual – 1 roll – Roll A1 (61.0 cm) |
|---|
Networking
Networking | Print server |
|---|
Security Protocols & Features | Wi-Fi Direct |
|---|
Expansion / Connectivity
Connections | 1 x USB 3.0
1 x Gigabit LAN – RJ-45 |
|---|
Miscellaneous
Included Accessories | Maintenance Tank |
|---|
Consumables Included | 1 x ink cartridge (cyan) – 26 ml
1 x ink cartridge (magenta) – 26 ml
1 x ink cartridge (yellow) – 26 ml
1 x ink cartridge (black) – 50 ml |
|---|
Compliant Standards | FCC Class A certified, CSA, UL, EMC, RoHS, MET |
|---|
Power
Power Device | Power supply – internal |
|---|
Frequency Required | 50 – 60 Hz |
|---|
Power Consumption Operational | 28 watt |
|---|
Power Consumption Stand by | 8 watt |
|---|
Power Consumption Sleep | 1.6 watt |
|---|
Software / System Requirements
Software Included | EpsonNet Print, EpsonNet Config |
|---|
OS Required | Microsoft Windows XP, Microsoft Windows Vista, Microsoft Windows 7 (32/64 bits), Apple MacOS X 10.8.x, Windows 8.1 (32/64 bits), Apple MacOS X 10.9.x, Apple MacOS X 10.10.x, Windows 10 (32/64 bits), Apple MacOS X 10.11.x, Apple macOS 10.12.x, Apple macOS 10.13.x |
|---|
Environmental Standards
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 20 – 80% (non-condensing) |
|---|
Sound Emission (Operating) | 49 dBA |
|---|
Dimensions & Weight
Width | 97 cm |
|---|
Depth | 50.5 cm |
|---|
Height | 23 cm |
|---|
Weight | 27 kg |
|---|
