Description
MikroTik created the perfect home lab router: compact, powerful, with multiple powering solutions and efficient cooling. RB5009 has it all, and even more!
The board features 9 wired ports and a full-sized USB 3.0. Seven of the ports are Gigabit Ethernet, another one is 2.5 Gigabit Ethernet, and the last one is a 10G SFP+ cage. All the ports are connected to a powerful Marvell Amethyst family switch-chip with a 10 Gbps full-duplex line leading to the Marvell Armada quad-core ARMv8 1.4 GHz CPU. Both CPU and the switch-chip are located on the bottom of the board – so the case acts as a massive heat-sink!
RB5009UG+S+IN can be powered in 3 different ways: PoE-in from Ethernet port, DC jack, 2-pin terminal on the side.
Boards offer large DDR4 RAM and NAND storage. This combination of ports and components, compared to the other products in a similar form factor, provides almost double the performance in configurations with heavy CPU loads.
You can mount four of these routers in a single 1U rackmount space! No more server-room-Tetris, just pure productivity.
Main Specifications
Product Description | MikroTik RB5009UG+S+IN – router – rack-mountable |
Device Type | Router |
Enclosure Type | Rack-mountable – 1U |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 10 Gigabit Ethernet |
Features | PoE, fanless, metal housing |
Compliant Standards | IEEE 802.3af, IEEE 802.3at |
Dimensions (WxDxH) | 22 cm x 12.5 cm x 2.2 cm |
Documents
Extended Specifications
General
Device Type | Router |
|---|
Enclosure Type | Rack-mountable – 1U |
|---|
Connectivity Technology | Wired |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 10 Gigabit Ethernet |
|---|
Features | PoE, fanless, metal housing |
|---|
Compliant Standards | IEEE 802.3af, IEEE 802.3at, EAC, RoHS |
|---|
Processor | 1 x ARM8 88F7040 1.4 GHz |
|---|
RAM | 1 GB |
|---|
Flash Memory | 1 GB |
|---|
Expansion / Connectivity
Interfaces | LAN: 7 x 10Base-T/100Base-TX/1000Base-TX – RJ-45
LAN: 1 x 2.5GBase-T (PoE) – RJ-45
LAN: 1 x 10Gb Ethernet – SFP+
USB 3.0: 1 x 9 pin USB Type A |
|---|
Power
Power Device | External power adapter |
|---|
Miscellaneous
Rack Mounting Kit | Optional |
|---|
MTBF | 200,000 hours |
|---|
Software / System Requirements
OS Provided | MikroTik RouterOS v7 |
|---|
Dimensions & Weight
Width | 22 cm |
|---|
Depth | 12.5 cm |
|---|
Height | 2.2 cm |
|---|
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
