Description
The GVC3220 is a high-end video conferencing system that provides an interactive and immersive video conferencing environment to increase collaboration and productivity. The SIP-based GVC3220 provides flexibility to support any SIP or H.323 video conferencing platform, including Grandstream’s IPVideoTalk Meetings. With IPVideoTalk, the GVC Option plan turns any meeting hosted on a GVC device into an online meeting that can be joined seamlessly by up to thousands of people from a web browser, mobile app or other GVC devices. The GVC3220 is based on Android 9.0 and offers powerful features including 4K Ultra HD video, the ability to locally host up to 5-way 1080p video conferences, wireless screen-sharing capabilities, integrated Wi-Fi, Bluetooth and more. It comes equipped with the GMD1208 desktop wireless microphone to enhance audio quality and provide full room coverage for up to 5m pickup range. Thanks to its suite of powerful, high-end video collaboration features, support for 4k Ultra HD video, ease-of-use and platform flexibility, the GVC3220 is ideal for boardrooms, large conference rooms, auditoriums, classrooms and more.
- Supports sharp video quality of up to 4K Full-HD video output
- Runs on Android 9.0 operating system
- Remote video screen realtime control and sharing PC screen functions
- GMD1208 desktop wireless microphone provides full room coverage for up to 5m pickup range
- Advanced camera with 8M pixel CMOS sensor, FOV wide-angle lens, 12x zoom and PTZ for easy camera view adjustments
- Integrated dual-band Wi-Fi 802.11 a/b/g/n/ac (2.4GHz & 5GHz), supports Wi-Fi Multimedia
- Integrated audio system
Equipped with a 4-microphone array, the Grandstream GVC3220 provides audio input, allowing for clear communication during meetings. - High-definition video capture
The integrated digital video camera offers 1080p capture resolution, ensuring that video quality meets the needs of any professional setting. - Flexible connectivity options
The device supports wired and wireless connections, providing flexibility for easy integration into various network environments. - Advanced video conferencing protocols
Designed with VoIP protocols and codecs, including SIP and Opus, the GVC3220 delivers audio and video for seamless conferencing. - User-friendly features
Includes a built-in microSD card reader and HDMI output, enabling recording, playback, and connection to external displays.
Main Specifications
Product Description | Grandstream GVC3220 – video conferencing device – power adapter included |
Device Type | Video conferencing device |
VoIP Protocols | SIP |
Codec | H.264, G.722, iLBC, G.722.1, G.722.1c, Opus, G.729A/B, G.711µ/a |
Dimensions (WxDxH) | 31 cm x 13 cm x 16.5 cm |
Weight | 1.98 kg |
Video Input | Digital video camera |
Video Output | Codec board – 1920 x 1080 |
Audio Input | 4-microphone array |
Input Device | Remote control (wireless) |
Networking | Network adapter – Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 EDR |
Power | AC 100-240 V (50/60 Hz) |
Extended Specifications
General
Device Type | Video conferencing device |
|---|
VoIP Protocols | SIP |
|---|
Voice Codecs | G.722, iLBC, G.722.1, G.722.1c, Opus, G.729A/B, G.711µ/a |
|---|
Video Codecs | H.264 |
|---|
Quality of Service | IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p |
|---|
Security | 256 bit AES |
|---|
Network Protocols | HTTP, HTTPS |
|---|
Width | 31 cm |
|---|
Depth | 13 cm |
|---|
Height | 16.5 cm |
|---|
Weight | 1.98 kg |
|---|
Built-in Devices | Microphone, camera, microSD card reader |
|---|
Video Input
Type | Digital video camera (colour) – integrated |
|---|
Digital Video Capture Resolution | 1080p |
|---|
Digital Zoom | 3 |
|---|
Features | ePTZ |
|---|
Video Output
Type | Codec board |
|---|
Max External Resolution | 1920 x 1080 |
|---|
Supported Display Graphics | XGA (1024×768), SVGA (800×600), SXGA (1280×1024), HDTV (1920×1080), HD (1280 x 720) |
|---|
Digital Video Standard | High-Definition Multimedia Interface (HDMI) |
|---|
Audio Input
Type | 4-microphone array – integrated |
|---|
Input Device
Type | Remote control |
|---|
Connectivity Technology | Wireless |
|---|
Networking
Type | Network adapter |
|---|
Connectivity Technology | Wireless, wired |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 EDR |
|---|
Network / Transport Protocol | TCP/IP, UDP/IP, NTP, ICMP/IP, PPPoE, ARP, DHCP, DNS, RTP, RTCP, HTTP, HTTPs |
|---|
Features | LDAP support, DiffServ support, Quality of Service (QoS), SSH support, LLDP-MED |
|---|
Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x |
|---|
Expansion / Connectivity
Interfaces | 1 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45
2 x audio / video – HDMI output – 19 pin HDMI Type A
1 x audio / video – HDMI input – 19 pin HDMI Type A
2 x USB |
|---|
Miscellaneous
Cables Included | 1 x HDMI cable – 1.5 m
1 x HDMI cable – 5 m
1 x network cable – 2 m |
|---|
Mounting Kit | Included |
|---|
Compliant Standards | EN 61000-3-2, EN 61000-3-3, EN55024, UL 60950, FCC Part 15 B, FCC Part 15 C, RoHS, EN 60950-1, AS/NZS 4268, FCC Part 15 E, ANATEL, AS/NZS 60950, EN 62311, EN 300 328, EN 301 489-1, EN 62479, EN 301 893, EN 55032, EN 301 489-17, AS/NZS CISPR 32 |
|---|
Power
Power Device | Power adapter – external |
|---|
Voltage Required | AC 100-240 V (50/60 Hz) |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 10 – 90% (non-condensing) |
|---|
