Shuttle XPC cube SH570R8, Barebone, mini PC LGA1200 Socket, Intel H570, no CPU, RAM 0 GB, Gigabit Ethernet, black
$1,319.50 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland, Wellington, or Christchurch
- Allow 1–2 days for delivery
- Add 1–2 days if you are rural
- Collection can be arranged
Description
Be able to access power whenever it is needed. This Shuttle Mini PC in cube format addresses professional users with exceptional CPU, RAM, graphics and storage space demands.
- 5.1 channel surround sound output for enhanced audio experience
- Expandable with four internal 3.5″ bays for added storage options
- ENERGY STAR certified for energy efficiency
- Supports dual-channel DDR4 memory for improved performance
- Multiple connection ports including DisplayPort, HDMI, and USB 3.2
- Versatile expansion capabilities
The Shuttle XPC cube SH570R8 offers four 3.5″ internal bays, providing the freedom to expand storage as needed. This allows for a tailored setup that can accommodate both current and future demands. - Robust connectivity options
With multiple ports including USB 3.2, DisplayPort, and HDMI, this mini PC ensures users have plenty of bandwidth for connecting peripherals and displays efficiently, making it ideal for diverse applications. - High efficiency power supply
The included 500-watt power supply meets 80 PLUS Gold certification standards, ensuring efficient power consumption while delivering reliable performance for all components. - Customizable performance
Equipped with an Intel H570 chipset and support for dual-channel DDR4 memory, users can easily upgrade components to suit individual performance needs, whether for gaming or demanding professional workloads. - Environmentally friendly design
This mini PC is ENERGY STAR certified, helping to reduce power consumption without sacrificing performance, reflecting a commitment to sustainability while delivering powerful computing capabilities.
Main Specifications
Product Description | Shuttle XPC cube SH570R8 – mini PC no CPU – 0 GB – no HDD |
Type | PC barebone – mini PC |
Processor | No CPU |
Processor Socket | LGA1200 Socket |
RAM | 0 GB (installed) / 128 GB (max) – DDR4 SDRAM |
Storage Controller | RAID (SATA 6Gb/s) |
Hard Drive | No HDD |
Optical Storage | No optical drive |
Graphics Controller | No graphics |
Audio Output | 5.1 channel surround |
Networking | 1GbE |
Power | (50/60 Hz) |
OS Provided | No operating system |
Colour | Black |
Dimensions (WxDxH) | 21.5 cm x 33.2 cm x 19 cm |
Weight | 3.5 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | PC barebone |
|---|---|
Product Form Factor | Mini PC |
Embedded Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip |
Colour | Black |
Processor / Chipset
CPU | No CPU |
|---|---|
Max CPU Qty | 1 |
CPU Upgradability | Upgradable |
CPU Socket | LGA1200 Socket |
Chipset Type | Intel H570 |
RAM
Installed Size | 0 GB (installed) / 128 GB (max) |
|---|---|
Technology | DDR4 SDRAM |
Form Factor | DIMM 288-pin |
Slots | 4 (Total) / 4 (empty) |
Features | Dual channel memory architecture |
Hard Drive
Type | No HDD |
|---|
Storage Controller
Type | 1 x RAID |
|---|---|
Controller Interface Type | SATA 6Gb/s |
Channel Qty | 4 |
RAID Level | RAID 0, RAID 1, RAID 5, RAID 10, JBOD |
Optical Storage
Type | No optical drive |
|---|
Monitor
Monitor Type | None. |
|---|
Graphics Controller
Graphics Processor | No graphics |
|---|
Audio Output
Sound Output Mode | 5.1 channel surround |
|---|---|
Compliant Standards | High Definition Audio |
Networking
Ethernet Ports | 2 x Gigabit Ethernet |
|---|---|
Ethernet Controller | Intel I219-LM, I210-AT |
Data Link Protocol | Ethernet, Gigabit Ethernet, Fast Ethernet |
Features | Wake on LAN (WoL), PXE support, Teaming support |
Expansion / Connectivity
Bays | 4 (total) / 4 (free) x internal 3.5″ |
|---|---|
Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 (PCIe 4.0 (11th Gen Intel CPUs), PCIe 3.0 (10th Gen Intel CPUs)) 1 (total) / 1 (free) x PCIe 3.0 x4 1 (total) / 1 (free) x M.2 Card – 2242/2260/2280 (Key M) 1 (total) / 1 (free) x M.2 Card – 2230 (Key E) |
Interfaces | 2 x microphone (1 front, 1 rear) 1 x headphones (1 in front) 1 x USB-C 3.2 Gen 1 (1 in front) 3 x USB 3.2 Gen 1 (3 in front) 4 x USB 3.2 Gen 2 1 x audio line-out 1 x HDMI 2 x DisplayPort 2 x LAN (Gigabit Ethernet) 1 x audio line-in 4 x USB 2.0 |
Miscellaneous
Included Accessories | Screw bag |
|---|---|
Cables Included | Serial ATA cable (2 pcs.) |
Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
Security Slot Type | Kensington security slot |
Compliant Standards | C-Tick, BSMI, CB, FCC, RoHS, ETL, ErP Ready, EMI, ErP 2009/125/EC, EMC 2014/30/EU, LVD 2014/35/EU |
Power
Device Type | Power supply |
|---|---|
Voltage Required | AC 100-240 V (50/60 Hz) |
Power Provided | 500 watt |
80 PLUS Certification | 80 PLUS Gold |
Power Factor Correction | Yes (active) |
Operating System / Software
OS Provided | No operating system |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|---|
ENERGY STAR Version | 5.0 |
Dimensions & Weight
Width | 21.5 cm |
|---|---|
Depth | 33.2 cm |
Height | 19 cm |
Weight | 3.5 kg |
Dimensions & Weight (Shipping)
Shipping Weight | 4.5 kg |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 – 90% |
