HPE Aruba AP-567 (RW) – Radio access point – ZigBee, Bluetooth, Wi-Fi 6 – 2.4 GHz, 5 GHz – BTO

Manufacturer:HP
Part Number:R4W48A
Warranty:Lifetime
PPID:AB08371

$1,255.44 inc GST

Free Delivery

5 in stock (can be backordered)

Ships from Auckland

Ships from Auckland

  • Allow 1-2 days for delivery to the North Island
  • Allow 2-3 days for delivery to the South Island
  • add 1-2 days if you are rural
  • Collection can be arranged

Description

Weatherproof and temperature hardened, Aruba 560 series access points deliver cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. Built to withstand extreme temperatures, persistent moisture and precipitation, electrical surges, and airborne contaminants.

  • Aruba 560 Series Outdoor Access Points include a built-in Policy Enforcement Firewall for Layer 7, deep packet inspection and role-based policy enforcement for each new client on the network.
  • Aruba 560 Series Outdoor Access Points include an integrated Aruba Bluetooth Low Energy beacon to provide enhanced IoT connectivity options.
  • Aruba 560 Series Outdoor Access Points are able to survive in harsh outdoor environments, withstanding exposure to high and low temperature extremes.

  • Simple and Secure Access
    Aruba 560 Series Outdoor Access Points include a built-in Policy Enforcement Firewall for Layer 7, deep packet inspection and role-based policy enforcement for each new client on the network.
    The Aruba 560 Series includes a hardware-based Trusted Platform Module for storage of credentials, keys, and booting with enhanced security.
    Utilizes Aruba ClearPass Policy Manager for centralized policy management.
  • IoT-ready
    Aruba 560 Series Outdoor Access Points include an integrated Aruba Bluetooth Low Energy beacon to provide enhanced IoT connectivity options.
    The built-in BLE beacon enables Meridian location and mobile engagement services.
    Select third-party Bluetooth infrastructure is also supported.
  • Extreme Weather Resiliency
    Aruba 560 Series Outdoor Access Points are able to survive in harsh outdoor environments, withstanding exposure to high and low temperature extremes.
    The Aruba 560 Series can also withstand wind speeds of up to 165 mph and tolerate persistent moisture, precipitation, and dust and salt sprays for extended periods of time.
    All electrical interfaces include industrial-strength surge protection.

Main Specifications

Product DescriptionHPE Aruba AP-567 (RW) – radio access point – ZigBee, Bluetooth, Wi-Fi 6
Device TypeRadio access point
Form FactorExternal – outdoor
Data Link ProtocolIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Frequency Band2.4 GHz, 5 GHz
PerformanceMaximum data rate (5 GHz): 1.2 Gbps
Maximum data rate (2.4 GHz): 574 Mbps
CapacityWireless clients per Wi-Fi radio: 256
BSSIDs per radio: 16
OFDMA units: 16
OS RequiredArubaOS, InstantOS 8.8.0.0
Power Over Ethernet (PoE) SupportedPoE+
Pricing TypeBTO
Dimensions (WxDxH)16.5 cm x 16.5 cm x 11 cm
Weight1.09 kg

Extended Specifications

General

Device TypeRadio access point
Ruggedized DesignOutdoor
Width16.5 cm
Depth16.5 cm
Height11 cm
Weight1.09 kg

Networking

Form FactorExternal
Connectivity TechnologyWireless
Data Transfer Rate1.49 Gbps
Line Coding FormatCCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
Data Link ProtocolIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Spread Spectrum MethodOFDM, DSSS, OFDMA
Frequency Band2.4 GHz, 5 GHz
PerformanceMaximum data rate (5 GHz): 1.2 Gbps
Maximum data rate (2.4 GHz): 574 Mbps
CapacityWireless clients per Wi-Fi radio: 256
BSSIDs per radio: 16
OFDMA units: 16
Status IndicatorsSystem, status, radio
FeaturesAuto-uplink (auto MDI/MDI-X), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility Controller mode, Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), High-Throughput (HT) support, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), waterproof, 2×2 MIMO technology, Very High Throughput (VHT) support, High Efficiency (HE) support, Target Wait Time (TWT), hardened, Wi-Fi 6 technology, Policy Enforcement Firewall (PEF), Layer 7 Deep Packet Inspection (DPI), Passpoint Release 2
Encryption AlgorithmWPA3-Enhanced Open, WPA2-MPSK

Aerial

AntennaInternal
DirectivityDirectional

Internet of Things (IoT)

Internet of Things (IoT) CompatibleYes
Communications TechnologyBluetooth Low Energy (LE), Zigbee

Expansion / Connectivity

Interfaces1 x 1000Base-T – RJ-45
2 x aerial
1 x console – USB-C

Miscellaneous

Compliant StandardsCB, UL 2043, FCC, EN 60601-1-2, cTUVus, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, IEC/EN/UL 60950, ETSI 300 019-2-4, RED 2014/53/EU
Pricing TypeBTO

Power

Power Over Ethernet (PoE) SupportedPoE+
Power Consumption Operational15.6 Watt

Software / System Requirements

OS RequiredArubaOS, InstantOS 8.8.0.0

Environmental Parameters

Min Operating Temperature-40 °C
Max Operating Temperature55 °C
Humidity Range Operating5 – 95% (non-condensing)
