Description
A powerful storage solution for businesses and IT enthusiasts with redundancy and service continuity features.
- Compact and reliable
- Redundant power
- Maximize service availability
- Data integrity and protection
- With room to grow with you
- Hyper Backup
- Snapshot Replication
- Protect your entire office with Active Backup
- Compact and reliable
Built for space-sensitive deployments, the RS1221+ is equipped to handle heavy workloads in data-intensive environments. - Redundant power
Reduce the chance that power disruptions on a single distribution channel or PDU cause data and service availability degradation. - Maximize service availability
When paired with another identical unit, Synology High Availability enables automatic minute-level failover between two clustered servers in the event of a server failure to minimize service downtime. - Data integrity and protection
ECC memory and the Btrfs file system bring higher reliability and snapshot capabilities to help prevent data corruption and simplify data protection. - With room to grow with you
Easily upgrade the RS1221+ to match your usage environment, whether it’s for performance, faster networking, or higher storage capacity. - Hyper Backup
A comprehensive backup and recovery solution for added data protection. Create backup destinations locally, on another Synology device, rsync servers, or cloud-based destinations, such as Google Drive, Dropbox, S3-compatible destinations, and Synology C2 Storage, a dedicated backup destination for Synology devices. Deduplication, integrity checks, and incremental transfer technology reduce bandwidth and storage use. - Snapshot Replication
Easily schedule flexible point-in-time backups of shared folders and LUNs with an RPO as low as 5 minutes and recovery in seconds. Set up replication and failover to other Synology storage systems for fast RTOs and minimal service disruption. - Protect your entire office with Active Backup
The Active Backup suite enables administrators to easily secure their entire IT infrastructure by backing up mission-critical data to their NAS, including Windows and Linux workstations and servers, file servers, VMware and Hyper-V virtual machines, and Microsoft 365 and Google Workspace accounts. Benefit from deduplication, multiversioning to quickly jump back in time, and additional data efficiency optimizations for reduced bandwidth and storage use.
Main Specifications
Product Description | Synology RackStation RS1221+ – NAS server |
Device Type | NAS server |
Host Connectivity | Gigabit Ethernet |
Enclosure Type | Rack-mountable – 2U |
Max Supported Capacity | 108 TB |
Installed Devices / Modules Qty | 0 (installed) / 8 (max) |
Dimensions (WxDxH) | 48.2 cm x 30.66 cm x 8.8 cm |
Weight | 6.9 kg () |
Processor | 1 x Ryzen Embedded V1500B 2.2 GHz (Quad-Core) |
Storage Controller | RAID SATA 6Gb/s RAID 0, 1, 5, 6, 10, JBOD |
Networking | 10Mb LAN, 100Mb LAN, 1GbE |
IP Cameras Supported | 40 |
RAM | 4 GB |
Power | AC 120/230 V (50/60 Hz) |
System Requirements | Microsoft Windows 7 or later, Apple macOS 10.12 or later |
Extended Specifications
General
Device Type | NAS server |
|---|
Host Connectivity | Gigabit Ethernet |
|---|
Enclosure Type | Rack-mountable – 2U |
|---|
Total Storage Capacity | 0 GB |
|---|
Max Supported Capacity | 108 TB |
|---|
Installed Devices / Modules Qty | 0 (installed) / 8 (max) |
|---|
Width | 48.2 cm |
|---|
Depth | 30.66 cm |
|---|
Height | 8.8 cm |
|---|
Weight | 6.9 kg () |
|---|
Processor / Memory
Processors Installed | 1 x Ryzen Embedded V1500B 2.2 GHz |
|---|
Number of Cores | Quad-Core |
|---|
Max Supported Qty | 1 |
|---|
RAM | 4 GB (installed) / 32 GB (supported) – DDR4 |
|---|
Features | ECC |
|---|
Storage Controller
Type | RAID |
|---|
Interface Type | SATA 6Gb/s |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
|---|
Networking
Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
|---|
Network / Transport Protocol | PPTP, L2TP, iSCSI, FTP, SMB, NFS, HTTP, HTTPs, SMB v2, Telnet, SMB v3 |
|---|
Remote Management Protocol | SNMP, Telnet, SSH |
|---|
Network Services Compatibility | Microsoft Active Directory (AD), Microsoft CIFS, FTP, Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1) |
|---|
Features | Firewall protection, LDAP support, WOL, Syslog support, antivirus analysis, High Availability, video server, POP3 e-mail server, ACL support, RADIUS support, FTP server, e-mail server, reset button, surveillance station, DNS server, VPN Server, Link Aggregation, scheduler, failover protection, Btrfs, NV, file station, EXT4 file system, SSD trim, RAID migration, MailPlus server, hybrid backup sync |
|---|
Encryption Algorithm | AES, SSL, TLS |
|---|
Security DVR
Expansion / Connectivity
Expansion Bays | 8 (total) / 8 (free) x hot-swap – 2.5" / 3.5" |
|---|
Expansion Slots | 1 (total) / 1 (free) x PCI Express 3.0 x8
1 (total) / 1 (free) x expansion slot |
|---|
Interfaces | 4 x Ethernet 1000Base-T – RJ-45
2 x USB 3.2 Gen 1
1 x eSATA |
|---|
Miscellaneous
Features | Built-in 2 cooling fans, 80mm cooling fan |
|---|
Compliant Standards | VCCI, BSMI, CCC, FCC, AES, RoHS, KC, EAC, RCM |
|---|
Power
Power Device | Internal power supply |
|---|
Voltage Required | AC 120/230 V (50/60 Hz) |
|---|
Software / System Requirements
OS Required | Microsoft Windows 7 or later, Apple macOS 10.12 or later |
|---|
Environmental Parameters
Min Operating Temperature | 5 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 5 – 95% |
|---|
Sound Emission | 40 dBA |
|---|
