Noctua NH-D15, Processor cooler, (for: AM2, AM2+, AM3, AM3+, AM4, AM5, FM1, FM2, FM2+, LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA1700, LGA2011, LGA2011-3, LGA2011 (Square ILM), LGA2011-3 (Square ILM), LGA2066), aluminum with nickel plated copper base, 140 mm, chromax.black
$204.49 inc GST
✓ In Stock - 5 available
✓ Free NZ Delivery
5 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
Built on the basis of the legendary NH-D14 and carrying on its quest for ultimate quiet cooling performance, Noctua’s flagship model NH-D15 is an elite-class dual tower cooler for the highest demands. Its expanded heatpipe layout and two premium grade NF-A15 140 mm fans with PWM support for automatic speed control allow it to further improve the NH-D14’s award-winning efficiency.
- 6 heatpipe dual tower design
- Widened fin stack and expanded heatpipe layout
- High RAM compatibility in single fan mode
- Dual NF-A15 140 mm fans
- PWM support and low-noise adaptor
- Excellent component cooling
- Based on the award-winning NH-D14
Noctua’s NH-D14 has received more than 350 awards and recommendations from leading international hardware websites and magazines, making it one of the most successful premium heatsinks ever built. With its expanded layout and dual NF-A15 fans, the NH-D15 further improves the D14’s much acclaimed quiet cooling performance. - 6 heatpipe dual tower design
As compared to conventional single tower heatinks, the NH-D15’s fine-tuned six heatpipe dual tower design provides more surface area, better heat-distribution and superior airflow efficiency in dual fan mode. - Widened fin stack and expanded heatpipe layout
Compared to the NH-D14, the NH-D15’s fin-stack has been widened from 140 to 150 mm and its heatpipes are now spaced further apart, which allows for a more uniform heat distribution over a larger surface area and thus contributes to the NH-D15’s superior efficiency. - High RAM compatibility in single fan mode
Thanks to its recessed lower fins, the NH-D15 provides 64 mm clearance for tall memory heatsinks in single fan mode, making it compatible with most high end RAM modules on the market. In dual fan mode, the NH-D15 should be used with standard height RAM. - Dual NF-A15 140 mm fans
The NH-D15 features two of Noctua’s premium class NF-A15 140 mm fans. Complying with Noctua’s AAO standard and featuring sophisticated aerodynamic design measures such as flow acceleration channels, the NF-A15 has quickly built up a reputation as one of the best 140 mm fans on the market. - PWM support and low-noise adaptor
The NF-A15 premium fans supplied with the NH-D15 support PWM for convenient automatic speed control through the mainboard. In addition, the maximum fan speed can be reduced from 1500 to 1200-rpm using the supplied low-noise adaptor for even quieter operation. - Excellent component cooling
Extending below the fin-stacks, the large NF-A15 fans not only contribute to the NH-D15’s superb CPU cooling capabilities but also provide massive airflow over surrounding motherboard components and heatsinks, thus ensuring excellent component cooling performance.
Main Specifications
Product Description | Noctua NH-D15 – processor cooler |
Product Type | Processor cooler |
Package Content | Low-Noise Adapter (L.N.A.), 4 vibration isolators, SecuFirm2 Mounting Kit, NT-H1 thermal paste, extension cable (30 cm), 4-pin PWM Y-cable, 4 fan screws |
Colour | Chromax.black |
Compatibility | Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket AM5, Socket FM1, Socket FM2, Socket FM2+, LGA1150 Socket, LGA1151 Socket, LGA1155 Socket, LGA1156 Socket, LGA1200 Socket, LGA1700 Socket, LGA2011 Socket, LGA2011-3 Socket, LGA2011 (Square ILM) Socket, LGA2011-3 (Square ILM) Socket, LGA2066 Socket |
Heatsink Material | Aluminum with nickel plated copper base |
Fans Qty | Dual |
Fan Diameter | 140 mm |
Fan Height | 25 mm |
Fan Bearing | SSO2 bearing |
Rotation Speed | 300-1500 rpm |
Air Flow | 68-82.5 cfm |
Noise Level | 19.2 – 24.6 dBA |
Power Connector | 4-pin fan connector |
Rated Voltage | 12 V |
Features | Heat pipe technology, Pulse-width modulation (PWM) support, 6 copper heatpipes, Soldered joints, Dual-Tower design |
Dimensions (WxDxH) | 15 cm x 16.1 cm x 16.5 cm |
Weight | 1.32 kg |
Extended Specifications
General
Product Type | Processor cooler |
|---|---|
Package Content | Low-Noise Adapter (L.N.A.), 4 vibration isolators, SecuFirm2 Mounting Kit, NT-H1 thermal paste, extension cable (30 cm), 4-pin PWM Y-cable, 4 fan screws |
Width | 15 cm |
Depth | 16.1 cm |
Height | 16.5 cm |
Weight | 1.32 kg |
Colour | Chromax.black |
Heatsink & Fan
Compatible With | Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket AM5, Socket FM1, Socket FM2, Socket FM2+, LGA1150 Socket, LGA1151 Socket, LGA1155 Socket, LGA1156 Socket, LGA1200 Socket, LGA1700 Socket, LGA2011 Socket, LGA2011-3 Socket, LGA2011 (Square ILM) Socket, LGA2011-3 (Square ILM) Socket, LGA2066 Socket |
|---|---|
Heatsink Material | Aluminum with nickel plated copper base |
Heatsink Dimensions | 160 mm x 150 mm x 135 mm |
Fans Qty | 2 |
Fan Diameter | 140 mm |
Fan Height | 25 mm |
Fan Bearing | SSO2 bearing |
Rotation Speed | 300-1500 rpm |
Air Flow | 68-82.5 cfm |
Noise Level | 19.2 – 24.6 dBA |
Noise & Performance Details | 19.2 dBA / 68 cfm at 1200 rpm 24.6 dBA / 82.5 cfm at 1500 rpm |
Power Connector | 4-pin fan connector |
Rated Voltage | 12 V |
Features | Heat pipe technology, Pulse-width modulation (PWM) support, 6 copper heatpipes, Soldered joints, Dual-Tower design |
Miscellaneous
MTBF | 150,000 hour(s) |
|---|
Additional information
| Compatible Socket | AM2, AM3, AM4, AM5, FM1, FM2, LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA1700, LGA2011, LGA2011-3, LGA2011-3(SquareILM), LGA2011(SquareILM), LGA2066 |
|---|---|
| Manufacturer | |
| Colour |
