Noctua NH-D15 – Processor cooler – (for: LGA1156, AM2, AM2+, AM3, LGA1155, AM3+, LGA2011, FM1, FM2, LGA1150, FM2+, LGA2011-3, LGA1151, LGA2011 (Square ILM), LGA2011-3 (Square ILM), AM4, LGA2066, LGA1200, LGA1700, AM5) – aluminum with nickel plated copper base – 140 mm – chromax.black

Manufacturer:Noctua
Part Number:NH-D15-CH-BK
Warranty:6 Years
PPID:AB06680

$190.12 inc GST

Free Delivery

5 in stock (can be backordered)

Description

Built on the basis of the legendary NH-D14 and carrying on its quest for ultimate quiet cooling performance, Noctua’s flagship model NH-D15 is an elite-class dual tower cooler for the highest demands. Its expanded heatpipe layout and two premium grade NF-A15 140 mm fans with PWM support for automatic speed control allow it to further improve the NH-D14’s award-winning efficiency.

  • 6 heatpipe dual tower design
  • Widened fin stack and expanded heatpipe layout
  • High RAM compatibility in single fan mode
  • Dual NF-A15 140 mm fans
  • PWM support and low-noise adaptor
  • Excellent component cooling

  • Based on the award-winning NH-D14
    Noctua’s NH-D14 has received more than 350 awards and recommendations from leading international hardware websites and magazines, making it one of the most successful premium heatsinks ever built. With its expanded layout and dual NF-A15 fans, the NH-D15 further improves the D14’s much acclaimed quiet cooling performance.
  • 6 heatpipe dual tower design
    As compared to conventional single tower heatinks, the NH-D15’s fine-tuned six heatpipe dual tower design provides more surface area, better heat-distribution and superior airflow efficiency in dual fan mode.
  • Widened fin stack and expanded heatpipe layout
    Compared to the NH-D14, the NH-D15’s fin-stack has been widened from 140 to 150 mm and its heatpipes are now spaced further apart, which allows for a more uniform heat distribution over a larger surface area and thus contributes to the NH-D15’s superior efficiency.
  • High RAM compatibility in single fan mode
    Thanks to its recessed lower fins, the NH-D15 provides 64 mm clearance for tall memory heatsinks in single fan mode, making it compatible with most high end RAM modules on the market. In dual fan mode, the NH-D15 should be used with standard height RAM.
  • Dual NF-A15 140 mm fans
    The NH-D15 features two of Noctua’s premium class NF-A15 140 mm fans. Complying with Noctua’s AAO standard and featuring sophisticated aerodynamic design measures such as flow acceleration channels, the NF-A15 has quickly built up a reputation as one of the best 140 mm fans on the market.
  • PWM support and low-noise adaptor
    The NF-A15 premium fans supplied with the NH-D15 support PWM for convenient automatic speed control through the mainboard. In addition, the maximum fan speed can be reduced from 1500 to 1200-rpm using the supplied low-noise adaptor for even quieter operation.
  • Excellent component cooling
    Extending below the fin-stacks, the large NF-A15 fans not only contribute to the NH-D15’s superb CPU cooling capabilities but also provide massive airflow over surrounding motherboard components and heatsinks, thus ensuring excellent component cooling performance.

Main Specifications

Product DescriptionNoctua NH-D15 – processor cooler
Product TypeProcessor cooler
Package ContentLow-Noise Adaptor (L.N.A.), 4 vibration isolators, SecuFirm2 Mounting Kit, NT-H1 thermal paste, extension cable (30 cm), 4-pin PWM Y-cable, 4 fan screws
ColourChromax.black
CompatibilityLGA1156 Socket, Socket AM2, Socket AM2+, Socket AM3, LGA1155 Socket, Socket AM3+, LGA2011 Socket, Socket FM1, Socket FM2, LGA1150 Socket, Socket FM2+, LGA2011-3 Socket, LGA1151 Socket, LGA2011 (Square ILM) Socket, LGA2011-3 (Square ILM) Socket, Socket AM4, LGA2066 Socket, LGA1200 Socket, LGA1700 Socket, Socket AM5
Heatsink MaterialAluminum with nickel plated copper base
Fans QtyDual
Fan Diameter140 mm
Fan Height25 mm
Fan BearingSSO2 bearing
Rotation Speed300-1500 rpm
Air Flow68-82.5 cfm
Noise Level19.2 – 24.6 dBA
Power Connector4-pin fan connector
Rated Voltage12 V
FeaturesHeat pipe technology, Pulse-width modulation (PWM) support, 6 copper heatpipes, Soldered joints, Dual-Tower design
Dimensions (WxDxH)15 cm x 16.1 cm x 16.5 cm
Weight1.32 kg
Manufacturer Warranty6-year warranty

Extended Specifications

General

Product TypeProcessor cooler
Package ContentLow-Noise Adaptor (L.N.A.), 4 vibration isolators, SecuFirm2 Mounting Kit, NT-H1 thermal paste, extension cable (30 cm), 4-pin PWM Y-cable, 4 fan screws
Width15 cm
Depth16.1 cm
Height16.5 cm
Weight1.32 kg
ColourChromax.black

Heatsink & Fan

Compatible WithLGA1156 Socket, Socket AM2, Socket AM2+, Socket AM3, LGA1155 Socket, Socket AM3+, LGA2011 Socket, Socket FM1, Socket FM2, LGA1150 Socket, Socket FM2+, LGA2011-3 Socket, LGA1151 Socket, LGA2011 (Square ILM) Socket, LGA2011-3 (Square ILM) Socket, Socket AM4, LGA2066 Socket, LGA1200 Socket, LGA1700 Socket, Socket AM5
Heatsink MaterialAluminum with nickel plated copper base
Heatsink Dimensions160 mm x 150 mm x 135 mm
Fans Qty2
Fan Diameter140 mm
Fan Height25 mm
Fan BearingSSO2 bearing
Rotation Speed300-1500 rpm
Air Flow68-82.5 cfm
Noise Level19.2 – 24.6 dBA
Noise & Performance Details19.2 dBA / 68 cfm at 1200 rpm
24.6 dBA / 82.5 cfm at 1500 rpm
Power Connector4-pin fan connector
Rated Voltage12 V
FeaturesHeat pipe technology, Pulse-width modulation (PWM) support, 6 copper heatpipes, Soldered joints, Dual-Tower design

Miscellaneous

MTBF150,000 hour(s)

Manufacturer Warranty

Service & SupportLimited warranty: – 6 years
