Description
Featuring a modern office design that compliments its environment and performance to match. Print multi-size jobs easily with auto switching between roll and tray. Enjoy high-speed printing as fast as 26 sec per A1/D plot. 1 GB memory.
Dynamic security enabled printer
Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges.
- Design that performs, technology that stands out.
- Print multi-size A3/B and A1/D projects automatically, without manually switching the media source.
- Avoid waiting by the printer with high-speed printing as fast as 26 seconds per A1/D plot.
What’s in the Box
- HP DesignJet Studio 24-in Printer, printer stand, automatic sheet feeder, roll cover, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord
Main Specifications
Product Description | HP DesignJet Studio – large-format printer – colour – ink-jet |
Printer Type | 24″ large-format printer – ink-jet – colour |
Weight | 33.6 kg |
Inkjet Technology | HP Thermal Inkjet |
Ink Palette Supported (Colours) | 4-ink – cyan, magenta, yellow, pigment black |
Max Media Size | Roll (61 cm x 45.7 m), ANSI D (559 x 864 mm) |
Min Media Size (Custom) | 210 mm x 279 mm |
Max Media Size (Custom) | 610 mm x 45.7 m |
Print Speed | Up to 0.43 min/page – black draft – ANSI D (559 x 864 mm)
Up to 0.43 min/page – colour draft – ANSI D (559 x 864 mm)
Up to 0.43 min/page – black draft – A1 (594 x 841 mm)
Up to 0.43 min/page – colour draft – A1 (594 x 841 mm) |
Max Resolution (B&W) | 2400 x 1200 dpi |
Max Resolution (Colour) | 2400 x 1200 dpi |
Cutter | Yes |
Interface | Gigabit LAN, USB 2.0, Wi-Fi(n) |
RAM Installed (Max) | 1 GB (1 GB) |
Language Simulation | HP GL/2, HP RTL, CALS G4, JPEG, URF |
Media Type | Bond paper, film, technical paper, plain paper, photo paper, glossy paper, self-adhesive paper, semi-gloss paper |
Total Media Capacity | 1 roll |
Networking | Print server |
Printer Features | 4.1 kg max roll weight, print from mobile device |
Power | AC 100-240 V |
Enclosure Colour | Wood |
Dimensions (WxDxH) | 101.3 cm x 55.5 cm x 93.2 cm |
Documents
Extended Specifications
Environmental Parameters
Max Operating Temperature | 40 °C |
|---|
Min Operating Temperature | 5 °C |
|---|
Printer
Connectivity Technology | Wireless |
|---|
Power
Frequency Required | 50/60 Hz |
|---|
Power Device | Power supply – internal |
|---|
Power Consumption Operational | 35 Watt |
|---|
Environmental Parameters
Sound Emission (Operating) | 42 dBA |
|---|
Dimensions & Weight (Shipping)
Networking
Dimensions & Weight
Printer
Environmental Standards
Printer
Max Resolution (B&W) | 2400 x 1200 dpi |
|---|
Max Resolution (Colour) | 2400 x 1200 dpi |
|---|
Dimensions & Weight (Shipping)
Dimensions & Weight
Dimensions & Weight (Shipping)
Power
Voltage Required | AC 100-240 V |
|---|
RAM
RAM Installed (Max) | 1 GB / 1 GB (max) |
|---|
Media Handling
Max Media Size (Custom) | 610 mm x 45.7 m |
|---|
General
Power
Power Consumption Sleep | 2.1 Watt |
|---|
Electric Current Required | 1.2 A |
|---|
Dimensions & Weight
Environmental Parameters
Sound Emission (Idle) | 16 dBA |
|---|
Power
Power Consumption Stand by | 0.2 Watt |
|---|
Dimensions & Weight
Dimensions & Weight (Shipping)
Printer
Inkjet Technology | HP Thermal Inkjet |
|---|
Ink Palette Supported (Colours) | 4-ink – cyan, magenta, yellow, pigment black |
|---|
General
Printer Type | 24″ large-format printer – ink-jet – colour |
|---|
Printer
Built-in Devices | Control panel |
|---|
Media Handling
Min Media Size (Custom) | 210 mm x 279 mm |
|---|
Media Thickness Range | Up to 0.3 mm |
|---|
Printer
Minimum Ink Droplet Size | 12 pl (black), 5.5 pl (colour) |
|---|
Media Handling
Total Media Capacity | 1 roll |
|---|
Printer
Ink Cartridge Configuration | 4 cartridges (1 each: cyan, magenta, yellow, pigment black) |
|---|
Nozzle Configuration | 1376 nozzles |
|---|
Media Handling
Media Weight | 60 g/m² – 280 g/m² |
|---|
Expansion / Connectivity
Connections | 1 x USB 2.0 – 4 pin USB Type B
1 x Gigabit LAN – RJ-45 |
|---|
Environmental Parameters
Humidity Range Operating | 20 – 80% RH |
|---|
Printer
Print Speed | Up to 0.43 min/page – black draft – ANSI D (559 x 864 mm)
Up to 0.43 min/page – colour draft – ANSI D (559 x 864 mm)
Up to 0.43 min/page – black draft – A1 (594 x 841 mm)
Up to 0.43 min/page – colour draft – A1 (594 x 841 mm) |
|---|
Media Handling
Media Feeders | 1 x manual – 1 roll – Roll (61 cm x 45.7 m) weight: 60 g/m² – 280 g/m² |
|---|
Miscellaneous
Consumables Included | 1 x ink cartridge (cyan)
1 x ink cartridge (magenta)
1 x ink cartridge (yellow)
1 x ink cartridge (black)
1 x feed roller
1 x printhead |
|---|
Printer
Interface | Gigabit LAN, USB 2.0, Wi-Fi(n) |
|---|
Language Simulation | HP GL/2, HP RTL, CALS G4, JPEG, URF |
|---|
Media Handling
Media Type | Bond paper, film, technical paper, plain paper, photo paper, glossy paper, self-adhesive paper, semi-gloss paper |
|---|
Media Sizes | A4 (210 x 297 mm), A3 (297 x 420 mm), A2 (420 x 594 mm), A1 (594 x 841 mm), ANSI A (Letter) (216 x 279 mm), ANSI B (Ledger) (279 x 432 mm), ANSI C (432 x 559 mm), ANSI D (559 x 864 mm), Roll (61 cm x 45.7 m) |
|---|
Software / System Requirements
Software Included | HP Click, HP DesignJet Utility, HP Support Assistant, HP Easy Start, HP Print Preview, HP Smart App |
|---|
Printer
Printer Features | 4.1 kg max roll weight, print from mobile device |
|---|
Media Handling
Max Media Size | Roll (61 cm x 45.7 m), ANSI D (559 x 864 mm) |
|---|
Miscellaneous
Included Accessories | Stand, spindle, setup poster, media bin, roll cover |
|---|
Compliant Standards | FCC Class B certified, ICES Class B, RED, EMC Class B, ACMA, RSM, CCC Class B, VCCI Class B, KCC Class B, WEEE, RoHS, REACH, ERP, CSA, LVD, EN 60950-1, EN 62368-1, EAC, UA, PSB, CCC, IRAM, BIS, NYCE |
|---|
