Description
It provides 950VA and 520W of power and nominal output voltage of 230V. It includes 4 Australian outlets for battery backup and surge protection. The UPS features a lead-acid battery with a recharge time of 8 hours.
- Provides 950VA and 520W of power, suitable for protecting multiple devices during power outages
- AVR corrects voltage variations, ensuring stable power supply
- Easy-to-read LED display provides real-time status of unit and utility power conditions
- Allows the UPS to be powered on even when utility power is unavailable
- Efficient power management
With efficiencies up to 97.1% at full load, the APC Back-UPS BX Series ensures minimal energy waste and lower energy costs. Its Automatic Voltage Regulation (AVR) maintains a steady output, even under fluctuating input voltages, safeguarding your equipment against power irregularities. - Reliable connectivity protection
The inclusion of RJ-45 dataline surge protection guards your network connections against surges and spikes. This feature is crucial for maintaining the integrity of your network’s data and hardware components, providing peace of mind in volatile electrical environments. - Quick recovery
A swift recharge time of 8 hours from empty to full ensures your UPS is ready to provide uninterrupted power protection. Coupled with a run time of up to 6.5 minutes at 50% load, it offers reliable short-term backup to safely shut down systems or switch to alternate power sources. - Comprehensive environmental adaptability
Designed to operate within a wide range of temperatures (0°C to 40°C) and humidity (0 – 95% non-condensing), the APC Back-UPS BX Series is built to withstand diverse operating environments. This adaptability ensures consistent performance, regardless of the conditions. - Enhanced auditory and visual alerts
Equipped with LED indicators and an audible alarm, the UPS provides immediate notification of changing utility power and UPS power conditions. This feature allows for prompt response to potential issues, ensuring that critical systems remain operational.
Main Specifications
Product Description | APC Back-UPS BX Series BX950MI-AZ – UPS – 520 Watt – 950 VA |
Device Type | UPS – external |
Weight | 6.1 kg |
Input Voltage | AC 230 V |
Output Voltage | AC 230 V ± 10% |
Power Capacity | 520 Watt / 950 VA |
Input Connectors | 1 x power AS/NZS 3112 |
Output connectors | 4 x power |
Battery | Lead Acid |
Run Time (Up To) | 1 min at full load |
Colour | Black |
Dimensions (WxDxH) | 12 cm x 35.5 cm x 16 cm |
Documents
Extended Specifications
General
Device Type | UPS – external |
|---|
Colour | Black |
|---|
Power Device
UPS Technology | Off-line |
|---|
Input Voltage | AC 230 V |
|---|
Input Voltage Range | AC 140 – 300 V |
|---|
Frequency Provided | 50/60 Hz ± 1Hz |
|---|
Frequency Required | 50/60 Hz ± 5Hz |
|---|
Input Connectors | 1 x power AS/NZS 3112 |
|---|
Power Output Connectors Details | 4 x power |
|---|
Output Voltage | AC 230 V ± 10% – 50/60 Hz |
|---|
Power Capacity | 520 Watt / 950 VA |
|---|
Dataline Surge Protection | Network – RJ-45 – 1 input line / 1 output line |
|---|
Output Waveform | Stepped approximation to a sinewave |
|---|
Surge Suppression | Yes |
|---|
Surge Energy Rating | 273 Joules |
|---|
Efficiency | 90.5% at 25% Load, 94.9% at 50% Load, 97.1% at 100% Load, 96.4% at 75% Load |
|---|
Power Factor (PF) | 0.54 |
|---|
Battery
Technology | Lead Acid |
|---|
Run Time (Up To) | 6.5 min at 50% load
1 min at full load |
|---|
Recharge Time | 8 hours |
|---|
Transfer Time | 6 ms |
|---|
Miscellaneous
Cables Included | Power cable – external – 1.22 m |
|---|
Equipment Protection Value | 50000 Euros |
|---|
Features | Audible alarm, Automatic Voltage Regulation (AVR), LED indicators |
|---|
Compliant Standards | CB, IEC 62040-2, RoHS, EN 62040-2, IP20, IEC 62040-1, EN 62040-1 |
|---|
Software / System Requirements
Software Included | APC PowerChute Personal Edition |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 0 – 95% (non-condensing) |
|---|
Sound Emission | 40 dBA |
|---|
Dimensions & Weight
Width | 12 cm |
|---|
Depth | 35.5 cm |
|---|
Height | 16 cm |
|---|
Weight | 6.1 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 19.7 cm |
|---|
Shipping Depth | 43 cm |
|---|
Shipping Height | 25 cm |
|---|
Shipping Weight | 6.6 kg |
|---|
