HP DesignJet T230, 24" large-format printer, colour, ink-jet, Roll (61 cm), 2400 x 1200 dpi, up to 0.58 min/page (mono) / up to 0.58 min/page (colour), capacity: 1 roll, USB 2.0, Gigabit LAN, Wi-Fi(n), cutter
$1,538.15 inc GST
1 in stock (can be backordered)
Ships from Auckland or Christchurch
- Allow 1-2 days for delivery
- add 1-2 days if you are rural
- No Collections
Description
Designed to fit your office, budget, and the way you work, the world’s smallest plotters provide outstanding simplicity. Send multiple files in just one click. Print your A1/D plot as fast as 35 seconds. 500 MB memory.
Dynamic security enabled printer
Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges.
- Save time with the world’s easiest job submission—send multiple files in one click with HP Click.
- Save space with the world’s smallest plotters designed to fit your office.
- Avoid waiting by the printer with high-speed printing as fast as 35 seconds per A1/D plot.
- Extreme simplicity
Print with confidence you’ll get the results you expect with an intuitive driver and true print preview. You can also send multiple files in one click with HP Click software. - Fits your office and budget
These compact plotters improve efficiency to meet space limitations and budgetary requirements. Not just a compact plotter, it’s also made from up to 30% recycled plastic. - Fits the way you work
With the HP Smart app you can print virtually from anywhere with your smartphone or tablet. Stand by anything other than a printer.
What’s in the Box
- HP DesignJet T230 24-in Printer, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord
Main Specifications
Product Description | HP DesignJet T230 – large-format printer – colour – ink-jet |
Printer Type | 24″ large-format printer – ink-jet – colour |
Weight | 21.5 kg |
Inkjet Technology | HP Thermal Inkjet |
Ink Palette Supported (Colours) | 4-ink – cyan, magenta, yellow, pigment black |
Max Media Size | Roll (61 cm) |
Min Media Size (Custom) | 210 mm x 279 mm |
Max Media Size (Custom) | 610 mm |
Print Speed | Up to 0.58 min/page – black draft – ANSI D (559 x 864 mm) Up to 0.58 min/page – colour draft – ANSI D (559 x 864 mm) Up to 0.58 min/page – black draft – A1 (594 x 841 mm) Up to 0.58 min/page – colour draft – A1 (594 x 841 mm) |
Max Resolution (B&W) | 2400 x 1200 dpi |
Max Resolution (Colour) | 2400 x 1200 dpi |
Cutter | Yes |
Interface | USB 2.0, Gigabit LAN, Wi-Fi(n) |
RAM Installed (Max) | 512 MB (512 MB) |
Language Simulation | JPEG, URF |
Media Type | Bond paper, film, technical paper, plain paper, photo paper, glossy paper, self-adhesive paper, semi-gloss paper |
Total Media Capacity | 1 roll |
Networking | Print server |
Printer Features | Print from mobile device, 4.1 kg max roll weight |
Power | AC 120/230 V |
Environmental Standards | EPEAT Gold |
Dimensions (WxDxH) | 101.3 cm x 44 cm x 28.5 cm |
Documents
Extended Specifications
General
Printer Type | 24″ large-format printer – ink-jet – colour |
|---|
Printer
Inkjet Technology | HP Thermal Inkjet |
|---|---|
Ink Palette Supported (Colours) | 4-ink – cyan, magenta, yellow, pigment black |
Nozzle Configuration | 4 x 1376 nozzles |
Minimum Ink Droplet Size | 12 pl (black), 5.5 pl (colour) |
Ink Cartridge Configuration | 4 cartridges (1 each: cyan, magenta, yellow, pigment black) |
Print Speed | Up to 0.58 min/page – black draft – ANSI D (559 x 864 mm) Up to 0.58 min/page – colour draft – ANSI D (559 x 864 mm) Up to 0.58 min/page – black draft – A1 (594 x 841 mm) Up to 0.58 min/page – colour draft – A1 (594 x 841 mm) |
Built-in Devices | LCD display |
Connectivity Technology | Wireless |
Interface | USB 2.0, Gigabit LAN, Wi-Fi(n) |
Max Resolution (B&W) | 2400 x 1200 dpi |
Max Resolution (Colour) | 2400 x 1200 dpi |
Language Simulation | JPEG, URF |
Cutter | Yes |
Printer Features | Print from mobile device, 4.1 kg max roll weight |
RAM
RAM Installed (Max) | 512 MB / 512 MB (max) |
|---|
Media Handling
Media Type | Bond paper, film, technical paper, plain paper, photo paper, glossy paper, self-adhesive paper, semi-gloss paper |
|---|---|
Max Media Size | Roll (61 cm) |
Min Media Size (Custom) | 210 mm x 279 mm |
Max Media Size (Custom) | 610 mm |
Media Sizes | A4 (210 x 297 mm), A3 (297 x 420 mm), A2 (420 x 594 mm), A1 (594 x 841 mm), ANSI A (Letter) (216 x 279 mm), ANSI B (Ledger) (279 x 432 mm), ANSI C (432 x 559 mm), ANSI D (559 x 864 mm) |
Media Thickness Range | Up to 0.3 mm |
Media Weight | 60 g/m² – 280 g/m² |
Total Media Capacity | 1 roll |
Media Feeders | Input tray: 1 x manual – 1 roll – Roll (61 cm) weight: 60 g/m² – 280 g/m² |
Networking
Networking | Print server |
|---|
Expansion / Connectivity
Connections | 1 x USB 2.0 – 4 pin USB Type B 1 x Gigabit LAN – RJ-45 |
|---|
Miscellaneous
Included Accessories | Spindle, setup poster |
|---|---|
Consumables Included | 1 x printhead 1 x ink cartridge (cyan) 1 x ink cartridge (magenta) 1 x ink cartridge (yellow) 1 x ink cartridge (black) |
Compliant Standards | FCC, ICES, EMC, ACMA, RSM, CCC, IRAM, BIS, VCCI, KCC, RED, WEEE, RoHS, REACH, CSA, LVD, EN 60950-1, EN 62368-1, EAC, PSB, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Power
Power Device | Power supply – internal |
|---|---|
Voltage Required | AC 120/230 V |
Frequency Required | 50/60 Hz |
Electric Current Required | 1.2 A |
Power Consumption Operational | 35 watt |
Power Consumption Stand by | 0.2 watt |
Power Consumption Sleep | 2.1 watt |
Software / System Requirements
Software Included | HP Click, HP DesignJet Utility, HP Support Assistant |
|---|
Environmental Standards
EPEAT Compliant | EPEAT Gold |
|---|---|
ENERGY STAR | Yes |
Environmental Parameters
Min Operating Temperature | 5 °C |
|---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 20 – 80% |
Sound Emission (Idle) | 16 dBA |
Sound Emission (Operating) | 42 dBA |
Dimensions & Weight
Width | 101.3 cm |
|---|---|
Depth | 44 cm |
Height | 28.5 cm |
Weight | 21.5 kg |
Dimensions & Weight (Shipping)
Width (Shipping) | 115.5 cm |
|---|---|
Depth (Shipping) | 57.5 cm |
Height (Shipping) | 40.5 cm |
Weight (Shipping) | 28 kg |
