Description
Night-time monitoring is now easier than ever thanks to the DCS-8630LH. An integrated spotlight provides color night vision in complete darkness and its 150° wide angle view captures stunning Full HD 1080p video at 30 frames per second (fps). The DCS-8630LH lets you record snapshots and video clips to the Cloud for anytime access. Play back recordings from the Cloud or download footage to your mobile device from anywhere, anytime.
- Home surveillance, illuminated
- See more in the dark
- Hear and be heard
- Your footage, your choice
- Works with the Google Assistant and Alexa
- Edge-based person detection
- Glass-break detection adds another line of defense to your home surveillance
- Home surveillance, illuminated
Night-time monitoring is now easier than ever thanks to the DCS-8630LH. An integrated spotlight provides color night vision in complete darkness and its 150° wide angle view captures stunning Full HD 1080p video at 30 frames per second (fps). Its built-in smart home hub connects with other mydlink Smart DIY devices allowing you to create personalized, amazing automations throughout your home. - See more in the dark
Low-light environments are no match for the DCS-8630LH’s color night vision capabilities. Get round-the-clock monitoring with its 400 lumen spotlight illuminating complete darkness. Activate the spotlight manually or automatically when triggered by motion. Now you can see what’s happening outside your home, even in the dark of night. - Hear and be heard
With a built-in microphone and speaker, you can make your presence felt even when you’re not around. Hear live audio from your camera’s live view and speak into your mobile device to broadcast audio live to the scene to let whoever you can see know you’re watching, whether they’re meant to be there or not. - Your footage, your choice
The DCS-8630LH lets you record snapshots and video clips to the Cloud for anytime access. Play back recordings from the Cloud or download footage to your mobile device from anywhere, anytime. Alternatively, store your footage directly to a microSD card. With support for a whopping 256 GB you can save days-on-end of footage, and what’s more – it cleverly records over your old footage, leaving you with one less thing to worry about. - Works with the Google Assistant and Alexa
The camera plays nice with Alexa and the Google Assistant. Use voice controls to stream live video from your camera to Amazon Fire TV, Echo Show, Echo Spot or Google Chromecast. - Edge-based person detection
The DCS-8630LH comes with edge-based person detection which intelligently identifies human motion, minimizing false triggers and alarms. A passive infrared (PIR) sensor further reduces false triggers by using infrared heat technology to pick up motion caused by human or animals. No longer will you receive notifications every time a bug flies by or trees sway in the wind. Only capture motion that matters, as it happens. - Glass-break detection adds another line of defense to your home surveillance
The DCS-8630LH is one of the world’s first Smart Home cameras with an integrated glass break detector. If glass is broken, you’ll be notified immediately to keep your home and your loved ones safe if potential danger is near.
Main Specifications
Product Description | mydlink DCS-8630LH – network surveillance camera |
Device Type | Network surveillance camera – fixed – outdoor, indoor – weatherproof |
Audio | Yes: built-in speaker, two-way audio capability, built-in microphone |
Camera Mount Type | Wall mount, pole mount |
Dimensions (WxDxH) | 6 cm x 12.6 cm x 8.4 cm |
Weight | 237 g |
Connectivity Technology | Wireless |
Camera | Colour – Day&Night |
Max Resolution | 1920 x 1080 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Video Modes | 1080p |
Optical Sensor Type | CMOS – 1/2.9″ |
Focal Length Control | Fixed focal |
Focal Length | 2.7 mm |
Lens Iris | F/2.0 |
Interfaces | IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0 |
Platform | MyDlink Home |
Intelligent Assistant | Google Assistant, Alexa |
Voltage | DC 12 V |
Features | Alarm function, progressive scanning, image mirror, PIR-based motion detector, Push Notification, cloud recording, ONVIF (Profile S) support, infrared-cut filter, Colour Night Vision, sound detection, built-in spotlight, built-in Smart Home hub, Edge-Based Person Detection, glass-break detection |
Environmental Parameters (operating) | -25 °C – 45 °C; 20 – 90% (non-condensing) relative humidity |
Documents
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in speaker, two-way audio capability, built-in microphone |
|---|
Audio Formats | AAC-LC |
|---|
Camera Mount Type | Wall mount, pole mount |
|---|
Connectivity Technology | Wireless |
|---|
Width | 6 cm |
|---|
Depth | 12.6 cm |
|---|
Height | 8.4 cm |
|---|
Weight | 237 g |
|---|
Camera
Type | Colour – Day&Night – fixed – outdoor, indoor – weatherproof |
|---|
Digital Video Format | MPEG-2, H.264 |
|---|
Max Digital Video Resolution | 1920 x 1080 |
|---|
Motion Detection | Yes |
|---|
Video Modes | 1080p |
|---|
Infrared LEDs | Yes |
|---|
Infrared Distance | 7 m |
|---|
Digital Video Capture Resolution | 1920 x 1080, 1080p |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Still Image Capture Resolution | 1080p |
|---|
Features | Alarm function, progressive scanning, image mirror, PIR-based motion detector, Push Notification, cloud recording, ONVIF (Profile S) support, infrared-cut filter, Colour Night Vision, sound detection, built-in spotlight, built-in Smart Home hub, Edge-Based Person Detection, glass-break detection |
|---|
Image Sensor
Lens Construction
Type | Fixed focal |
|---|
Focal Length | 2.7 mm |
|---|
Lens Iris | F/2.0 |
|---|
Horizontal Field of View (degree) | 123.8 |
|---|
Vertical Field of View (degree) | 65.4 |
|---|
Diagonal Field of View (degree) | 150 |
|---|
Interfaces
Network Interface | IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0 |
|---|
Network Protocols | DHCP, DNS, RTSP, RTP, HTTPS, IPv4, IPv6, Bonjour, SRTP |
|---|
Expansion / Connectivity
Supported Memory Cards | microSD Card |
|---|
Miscellaneous
Included Accessories | Mounting hardware |
|---|
Compliant Standards | FCC Class B certified, BSMI, IC, IP65, LVD, NCC, RCM |
|---|
Power
Power Requirements | DC 12 V – 1 A |
|---|
Power Device | Power adapter – external AC 120/230 V (50/60 Hz) 8 Watt |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|
Hub | Included |
|---|
Platform | MyDlink Home |
|---|
Communications Technology | Zigbee |
|---|
Intelligent Assistant | Google Assistant, Alexa |
|---|
Environmental Parameters
Min Operating Temperature | -25 °C |
|---|
Max Operating Temperature | 45 °C |
|---|
Relative Humidity (operating) | 20 – 90% (non-condensing) |
|---|
