Description
High density, double-conversion on-line power protection with scalable runtime. A versatile UPS developed for harsh power conditions.
- Multi-function LCD status and control console
- Maintenance-free sealed battery with suspended electrolyte
Main Specifications
Product Description | APC Easy UPS SRV SRV1KI – UPS – 800 watt – 1000 VA |
Device Type | UPS – external |
Weight | 9.3 kg |
Input Voltage | AC 230 V |
Output Voltage | AC 230 V ± 3% |
Power Capacity | 800 watt / 1000 VA |
Input Connectors | 1 |
Battery | Lead Acid |
Networking | USB, RS-232 |
Dimensions (WxDxH) | 14.5 cm x 22.3 cm x 28.8 cm |
Extended Specifications
General
Device Type | UPS – external |
|---|
Power Device
UPS Technology | On-line |
|---|
Input Voltage | AC 230 V |
|---|
Input Voltage Range | AC 160 – 280 V |
|---|
Frequency Provided | 50/60 Hz |
|---|
Frequency Required | 40 – 70 Hz |
|---|
Input Connectors | 1 |
|---|
Output Voltage | AC 230 V ± 3% – 50/60 Hz |
|---|
Power Capacity | 800 watt / 1000 VA |
|---|
Output Waveform | Sinewave |
|---|
Efficiency | 88% |
|---|
Battery
Technology | Lead Acid |
|---|
Recharge Time | 5 hours |
|---|
Features | Sealed, maintenance free |
|---|
Networking
Remote Management Interface | USB, RS-232 |
|---|
Miscellaneous
Cables Included | USB cable – external
Serial cable – external |
|---|
Features | LCD display, internal bypass |
|---|
Software / System Requirements
Software Included | APC Easy Ups Online SNMP Shutdown Wizard |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 0 – 95% (non-condensing) |
|---|
Dimensions & Weight
Width | 14.5 cm |
|---|
Depth | 22.3 cm |
|---|
Height | 28.8 cm |
|---|
Weight | 9.3 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 23.5 cm |
|---|
Shipping Depth | 33 cm |
|---|
Shipping Height | 36.5 cm |
|---|
Shipping Weight | 10.6 kg |
|---|
