Draytek VigorSwitch G2280X, Switch, L2+, Managed, 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+, desktop, rack-mountable
$1,005.04 inc GST
✓ In Stock - 2 available
✓ Free NZ Delivery
2 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
DrayTek VigorSwitch G2280X is a Layer 2+ managed Gigabit switch ideal for a network with growing network traffic. The switch has 24 Gigabit Ethernet LAN ports. Link aggregation is supported to trunk up to 8 ports and increase bandwidth as needed. The switch provides various types of VLAN for you to segment the local network and keep the traffic only at where it needs to go. Moreover, it supports VLAN routing to route the inter-VLAN traffic directly, shares loads of the router, and improve overall network performance.
- Auto surveillance & voice VLAN
- Web-based GUI
- IP conflict prevention
- Central switch management
- Auto surveillance & voice VLAN
Recognize traffic from IP cameras and IP phones automatically and add CoS tag for QoS prioritization. - Web-based GUI
Easily manage and monitor the network through the web-based console with graphics showing ports and hardware status. - IP conflict prevention
Improve network stability by avoiding IP conflicts caused by a misconfigured or malicious host. - Central switch management
Set up VLAN easily from the router and get a centralized hierarchy view of the switches.
Main Specifications
Product Description | Draytek VigorSwitch G2280X – switch – 28 ports – Managed – rack-mountable |
Device Type | Switch – 28 ports – L2+ – Managed |
Enclosure Type | Rack-mountable |
Subtype | 10 Gigabit Ethernet |
Ports | 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ |
Performance | Switching capacity: 128 Gbps Buffer memory: 12 Mbit Forwarding rate: 95.2 Mpps |
Capacity | Multicast groups: 256 Total link aggregation groups: 8 VLANs supported: 256 QoS queues: 8 |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 12KB |
Routing Protocol | IGMPv2, static IP routing, IGMPv3, MLDv2, MLD |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI |
Features | Flow control, auto-negotiation, load balancing, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, E-mail alert, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, SNTP support, sFlow, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, reset button, IPv4 support, LLDP support, LACP, MVR, SPQ, loop prevention, port isolation, CoS, tagged VLAN, GVRP, ONVIF support, Protocol-based VLANs support, IP source guard, Link Aggregation, Voice VLAN, Private MIB, protected ports, EEE, WRR, DSCP based CoS, MAC based VLAN, port trunking, Unknown Storm Control, Q-in-Q tunnelling |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.3az |
Dimensions (WxDxH) | 44.1 cm x 19.7 cm x 4.5 cm |
Weight | 2.44 kg |
Extended Specifications
General
Device Type | Switch – 28 ports – L2+ – Managed |
|---|---|
Enclosure Type | Desktop, rack-mountable |
Subtype | 10 Gigabit Ethernet |
Ports | 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ |
Performance | Switching capacity: 128 Gbps Buffer memory: 12 Mbit Forwarding rate: 95.2 Mpps |
Capacity | Multicast groups: 256 Total link aggregation groups: 8 VLANs supported: 256 QoS queues: 8 |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 12KB |
Routing Protocol | IGMPv2, static IP routing, IGMPv3, MLDv2, MLD |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI |
Authentication Method | RADIUS, TACACS+, internal user database |
Features | Flow control, auto-negotiation, load balancing, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, E-mail alert, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, SNTP support, sFlow, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, reset button, IPv4 support, LLDP support, LACP, MVR, SPQ, loop prevention, port isolation, CoS, tagged VLAN, GVRP, ONVIF support, Protocol-based VLANs support, IP source guard, Link Aggregation, Voice VLAN, Private MIB, protected ports, EEE, WRR, DSCP based CoS, MAC based VLAN, port trunking, Unknown Storm Control, Q-in-Q tunnelling |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.3az |
Built-in Devices | Led panel |
Status Indicators | Power, system, link/activity |
Expansion / Connectivity
Interfaces | 24 x 1000Base-T RJ-45 4 x Gigabit / 10Gbit LAN SFP+ 1 x console RJ-45 management |
|---|
Power
Power Device | Internal power supply |
|---|---|
Power Consumption Operational | 25 Watt |
Miscellaneous
Included Accessories | Rubber feet |
|---|---|
Cables Included | 1 x console cable |
Rack Mounting Kit | Included |
Compliant Standards | FCC |
Dimensions & Weight
Width | 44.1 cm |
|---|---|
Depth | 19.7 cm |
Height | 4.5 cm |
Weight | 2.44 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 45 °C |
Humidity Range Operating | 10 – 90% (non-condensing) |
Min Storage Temperature | -20 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 5 – 90% (non-condensing) |
