APC Smart-UPS C SMC1500I-2UC, UPS (rack-mountable), AC 220/230/240 V, 900 Watt, 1500 VA, RS-232, USB, output connectors: 4, 2U, black, with APC SmartConnect
Manufacturer:APC
Part Number:SMC1500I-2UC
Warranty:2 Years
PPID:AA91639
$1,578.49 inc GST
3 in stock (can be backordered)
Ships from Auckland
- Allow 1-2 days for delivery to the North Island
- Allow 2-3 days for delivery to the South Island
- add 1-2 days if you are rural
- Collection can be arranged
SKU: AA91639
Categories: Components & Accessories, Hardware, Power Protection Devices, Rack-Mountable UPS
Description
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.- 1500VA/900W line interactive pure sine wave 2U rackmount UPS
- Ideal for entry-level servers, networks, retail POS, and business VOIP
- Automatic Voltage Regulation keeps output voltage within acceptable user selectable levels
- Cloud-based remote power monitoring via SmartConnect Ethernet Port
- Graceful shutdown using serial or USB cables via PowerChute Business Edition
- Input- IEC C14, Output- 4x IEC C13
- Peace of mind with 2-year UPS warranty
- Automatic Voltage Regulation (AVR) corrects utility voltage
- SmartConnect
Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services. - Software package
SmartConnect software for remote power monitoring feature availability varies by terms of use - Communication port support
SmartConnect Ethernet port for cloud monitoring feature availability varies by terms of use - High online efficiency
Reduces utility costs, generates less heat. - Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. - Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics. - LCD Status Display
Provides key UPS status at a glance. Multiple status indicators with load and battery bar graphs. - Cold-start capable
Provides temporary battery power when the utility power is out. - Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
What’s in the Box
- documentation CD
- installation guide
- rack mounting brackets
- USB cable
Main Specifications
Product Description | APC Smart-UPS C SMC1500I-2UC – UPS – 900 Watt – 1500 VA – with APC SmartConnect |
Device Type | UPS – rack-mountable |
Rack Size | 2U |
Weight | 28.64 kg |
Input Voltage | AC 220/230/240 V |
Output Voltage | AC 230 V ± 5% |
Power Capacity | 900 Watt / 1500 VA |
Input Connectors | 1 x power IEC 60320 C14 |
Output connectors | 4 x power IEC 60320 C13 2 x IEC jumper |
Battery | Lead Acid |
Batteries Qty | 1 |
Run Time (Up To) | 10.1 min at full load |
Networking | RS-232, USB |
Colour | Black |
Dimensions (WxDxH) | 43.2 cm x 47.7 cm x 8.6 cm |
Bundled with | APC SmartConnect |
Documents
Extended Specifications
Battery
Technology | Lead Acid |
---|---|
Run Time (Up To) | 10.1 min at full load 25 min at half load 173 min at 50 Watts 107 min at 100 Watts 59 min at 200 Watts 39.2 min at 300 Watts 28.6 min at 400 Watts 22.1 min at 500 Watts 17.6 min at 600 Watts 14.4 min at 700 Watts 12 min at 800 Watts 10.1 min at 900 Watts |
Recharge Time | 3 hours |
Features | Maintenance free |
Networking
Remote Management Interface | RS-232, USB |
---|
Expansion / Connectivity
Interfaces | 1 x management (USB) – 4 pin USB Type B 1 x serial – RJ-45 |
---|
Miscellaneous
Cables Included | Serial cable – external USB cable – external |
---|---|
Features | Audible alarm, LCD display, Automatic Voltage Regulation (AVR), cold-start function, automatic shut down reset, automatic self-test, hot-swappable batteries |
Compliant Standards | CSA, GOST, UL 1778, VDE, C-Tick |
Software / System Requirements
Software Included | APC PowerChute Business Edition |
---|
Environmental Parameters
Min Operating Temperature | 0 °C |
---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 0 – 95% |
Sound Emission | 46 dBA |
Dimensions & Weight
Width | 43.2 cm |
---|---|
Depth | 47.7 cm |
Height | 8.6 cm |
Weight | 28.64 kg |
Dimensions & Weight (Shipping)
Shipping Width | 59.4 cm |
---|---|
Shipping Depth | 60.3 cm |
Shipping Height | 25.1 cm |
Shipping Weight | 31.91 kg |
General
Device Type | UPS – rack-mountable |
---|---|
Height (Rack Units) | 2U |
Colour | Black |
Bundled with | APC SmartConnect |
Power Device
UPS Technology | Line interactive |
---|---|
Input Voltage | AC 220/230/240 V |
Input Voltage Range | AC 180 – 287 V |
Input Voltage Range (Adjustable) | AC 170 – 300 V |
Frequency Provided | 50/60 Hz ± 3Hz |
Frequency Required | 50/60 Hz ± 3Hz |
Input Connectors | 1 x power IEC 60320 C14 |
Power Output Connectors Details | 4 x power IEC 60320 C13 2 x IEC jumper |
Output Voltage | AC 230 V ± 5% – 50/60 Hz |
Power Capacity | 900 Watt / 1500 VA |
Output Waveform | Sinewave |
Surge Suppression | Yes |
Surge Energy Rating | 459 Joules |
Circuit Protection | Circuit breaker |
Battery
Quantity | 1 |
---|
