Description
This MST hub lets you connect three monitors to your DisplayPort (DP) 1.2 equipped Windows laptop or desktop.
The newest generations of computers are more portable than ever, which often means that you’re left with fewer video outputs and smaller integrated screens. This MST hub solves both of these problems by letting you connect three additional displays to your computer, which makes multitasking much easier.
With the MST hub, you can use DisplayPort video adapters and cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. This MST hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.
Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display giving you the freedom to multitask and increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.
MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming and medical imaging.
Note: When using a DisplayPort 1.1 video card the MSTDP123DP will act as splitter, automatically mirroring your video source across all displays. Resolution limitations apply.
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports. Certain graphics adapters have limited MST support and will only output to three displays in total. If more than three monitors are attached the fourth will be disabled.
What’s in the Box
- StarTech.com 3 Port DisplayPort MST Hub – 4K 30Hz – DisplayPort to DisplayPort Multi Monitor Splitter for 3 DP Monitor Setup (MSTDP123DP)
- External power adapter
Main Specifications
Product Description | Startech 3-Port Multi Monitor Adapter, DisplayPort 1.2 MST Hub, Dual 4K 30Hz & 1x 1080p, Video Splitter for Extended Desktop Mode on Windows PCs Only, DP to 3x DP Monitors MST Hub – Multi Stream Transport (MSTDP123DP) – video splitter – 3 ports |
Device Type | Video splitter – 3 ports |
Features | Plastic housing |
Power | AC 100/230 V |
Dimensions (WxDxH) | 7.8 cm x 38.6 cm x 2 cm |
Weight | 99 g |
Colour | Black |
Designed For | P/N: SV231DPU34K, SVA5N3NEUA |
Extended Specifications
General
Device Type | Video splitter – 3 ports |
|---|
Enclosure Type | Desktop |
|---|
Max Resolution | 2560 x 1600 |
|---|
Features | Plastic housing |
|---|
Expansion / Connectivity
Interfaces | 3 x DisplayPort
1 x DisplayPort |
|---|
Power
Power Device | External power adapter |
|---|
Voltage Required | AC 100/230 V |
|---|
Miscellaneous
Colour | Black |
|---|
Compliant Standards | FCC, RoHS |
|---|
Dimensions & Weight
Width | 7.8 cm |
|---|
Depth | 38.6 cm |
|---|
Height | 2 cm |
|---|
Weight | 99 g |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 22.9 cm |
|---|
Shipping Depth | 15.5 cm |
|---|
Shipping Height | 5.5 cm |
|---|
Shipping Weight | 409 g |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 45 °C |
|---|
Min Storage Temperature | -20 °C |
|---|
Max Storage Temperature | 70 °C |
|---|
Compatibility Information
Designed For | P/N: SV231DPU34K, SVA5N3NEUA |
|---|
