APC Smart-UPS RM 750VA USB, UPS (rack-mountable), AC 230 V, 480 Watt, 750 VA, output connectors: 4, 1U, black, for P/N: AR3003, AR3003SP, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP, AR9300SP
$1,354.75 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
APC’s slim line rack-mount Smart-UPS delivers premium uninterruptible power and the most advanced performance features available. With PowerChute plus software the uninterruptible power supply (UPS) will safely store data and shut down your network operating system before the battery is fully discharged, whether you’re there or not. SmartSlot internal accessory slot allows you to install optional accessories to enhance the performance of your UPS. Additionally, the APC NetShelter enclosure provides security, flexibility and proper management of all your rack-mount devices.
Main Specifications
Dimensions (WxDxH) | 48.3 cm x 66 cm x 4.4 cm |
Designed For | P/N: AR3003, AR3003SP, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP, AR3140G, AR3340G, AR3357X674, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, AR9300SP, AR9300SP-R, AR9307SP, AR9307SP-R, NBWL0356A |
Product Description | APC Smart-UPS RM 750VA USB – UPS – 480 watt – 750 VA |
Device Type | UPS – rack-mountable |
Rack Size | 1U |
Weight | 21.8 kg |
Input Voltage | AC 230 V |
Output Voltage | AC 230 V |
Power Capacity | 480 watt / 750 VA |
Input Connectors | 1 x power IEC 60320 C14 |
Output connectors | 4 x power IEC 60320 C13 |
Battery | Lead Acid |
Run Time (Up To) | 7.1 min at full load |
Colour | Black |
Documents
Extended Specifications
General
Device Type | UPS – rack-mountable |
|---|---|
Height (Rack Units) | 1U |
Colour | Black |
Power Device
UPS Technology | Line interactive |
|---|---|
Supported Battery Technology | Lead Acid |
Input Voltage | AC 230 V |
Input Voltage Range | AC 160 – 286 V |
Input Voltage Range (Adjustable) | AC 151 – 302 V |
Frequency Required | 50/60 Hz |
Input Connectors | 1 x power IEC 60320 C14 |
Power Output Connectors Details | 4 x power IEC 60320 C13 |
Output Voltage | AC 230 V |
Power Capacity | 480 watt / 750 VA |
Output Waveform | Sinewave |
Surge Suppression | Yes |
Surge Energy Rating | 480 joules |
Battery
Technology | Lead Acid |
|---|---|
Run Time (Up To) | 7.1 min at full load |
Expansion / Connectivity
Interfaces | 1 x management (USB) – 4 pin USB Type B 1 x management (RS-232) – 9 pin D-Sub (DB-9) |
|---|---|
Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
Miscellaneous
Cables Included | USB cable – external Serial cable – external |
|---|---|
Rack Mounting Kit | Included |
Features | LED display, audible alarm |
Compliant Standards | C-Tick, GOST, PCBC, UL 1449, VDE |
Software / System Requirements
Software Included | APC PowerChute Business Edition |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Min Storage Temperature | -15 °C |
Max Storage Temperature | 45 °C |
Humidity Range Operating | 0 – 95% |
Humidity Range Storage | 0 – 95% |
Dimensions & Weight
Width | 48.3 cm |
|---|---|
Depth | 66 cm |
Height | 4.4 cm |
Weight | 21.8 kg |
Compatibility Information
Designed For | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP9290, AR100, AR100HD, AR202, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3003, AR3003SP, AR3006, AR3006SP, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3103, AR3103SP, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3106, AR3106SP, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3357X674, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, AR8135BLK, AR9300SP, AR9300SP-R, AR9307SP, AR9307SP-R, NBWL0356A |
|---|
