Cambium Networks XV2-23T, Radio access point, Wi-Fi 6, 2.4 GHz, 5 GHz, pole mountable
$994.27 inc GST
✓ In Stock - 20 available
✓ Free NZ Delivery
20 in stock
Ships from: Christchurch
- Allow 2–3 days for delivery to the North Island
- Allow 1–2 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The XV2-23T outdoor 2×2 Wi-Fi 6 AP, equipped with long-range internal antennas, is ideal for hospitality, education, municipal, transportation, and logistics applications.
- Dual-radio Wi-Fi 6
- 5 GHz (2×2), 2.4 GHz (2×2) Wi-Fi bands
- 1 GbE uplink
- Outdoor IP67-rated enclosure
- Managed by cnMaestro or Swift
- Cost-effective Wi-Fi for any market
The Cambium Networks XV2-23T Wi-Fi 6 outdoor Access Point delivers a high performance-to-price ratio attractive to any market. The XV2-23T can be onboarded and managed by your choice Cambium management systems – cnMaestro X or cnMaestro Essentials, or the Swift mobile app. Choose the management type you need and change it at any time. - Designed for fast installation
The XV2-23T offers multiple installation methods. You can mount the AP to a pole using the included clamps, or to a flat surface using the integrated bracket. The XV2-23T is a compact, high-performance outdoor Wi-Fi 6 AP.
Main Specifications
Weight | 1.22 kg |
Product Description | Cambium Networks XV2-23T – radio access point – Wi-Fi 6 |
Device Type | Radio access point |
Form Factor | Pole mountable – outdoor |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6) |
Frequency Band | 2.4 GHz, 5 GHz |
Performance | Maximum data rate (5 GHz): 2402 Mbps Maximum data rate (2.4 GHz): 573.5 Mbps Channel width: 20 / 40 / 80 / 160 MHz |
Capacity | Concurrent clients: 256 SSIDs total: 16 |
Power Over Ethernet (PoE) Supported | PoE |
Dimensions (WxDxH) | 20 cm x 8.4 cm x 30 cm |
Extended Specifications
General
Device Type | Radio access point |
|---|---|
Ruggedized Design | Outdoor |
Width | 20 cm |
Depth | 8.4 cm |
Height | 30 cm |
Weight | 1.22 kg |
Networking
Form Factor | Pole mountable |
|---|---|
Connectivity Technology | Wireless |
Line Coding Format | 1024 QAM, 16 QAM, 256 QAM, 64 QAM, 4096 QAM, BPSK, CCK, QPSK, DSSS |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6) |
Spread Spectrum Method | OFDMA, OFDM, DSSS |
Network / Transport Protocol | L2TP, PPPoE, IPv4, IPv6 |
Routing Protocol | GRE |
Remote Management Protocol | Syslog, SNMP |
Frequency Band | 2.4 GHz, 5 GHz |
Performance | Maximum data rate (5 GHz): 2402 Mbps Maximum data rate (2.4 GHz): 573.5 Mbps Channel width: 20 / 40 / 80 / 160 MHz |
Capacity | Concurrent clients: 256 SSIDs total: 16 |
Features | Pre-Shared Key (PSK), security slot (Kensington security lock compatible), LED status indicators, cnMaestro support, cloud managed, Authentication, Authorization and Accounting (AAA), WLAN scheduling, 802.1x authentication, Wi-Fi Multimedia (WMM) support, opportunistic key caching (OKC), Mesh networking, NAT support, firewall protection, DHCP server, VLAN pooling, band steering, load balancing, SNMP traps, Airtime Fairness, transmit beamsteering, STBC support, Low Density Parity Check (LDPC), MIMO Power Save, Maximum Ratio Combining (MRC), DNS proxy |
Encryption Algorithm | WPA3, AES, WPA2-Enterprise, CCMP, WPA2, WPA, TKIP, WEP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS |
Authentication Method | RADIUS, MACAuth |
Compliant Standards | Wi-Fi CERTIFIED 6, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11w, IEEE 802.11r, IEEE 802.3ad (LACP), IEEE 802.11d, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11u, IEEE 802.11v, IEEE 802.11n |
Aerial
Antenna | Internal |
|---|
Expansion / Connectivity
Interfaces | 1 x 10/100/1000Base-T (PoE) – RJ-45 |
|---|
Miscellaneous
MTBF | 5,077,102 hour(s) |
|---|---|
Compliant Standards | IEEE 802.3af, PP2.0, FCC, IC, IEC 60950, IEC 62368, EN 50121, EN 61373 |
Power
Power Over Ethernet (PoE) Supported | PoE |
|---|---|
Power Consumption Operational | 11 Watt |
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|---|
Max Operating Temperature | 65 °C |
Humidity Range Operating | 0 – 95% RH (non-condensing) |
